reel roller

reel roller

For unwinding cable drums

DAR 1 SERIE L

CHARACTERISTICS

  • Ø mini : 250 mm.
  • Ø maximum: 1050mm.
  • Maximum width of cable drum: 640mm.
  • Maximum weight of cable drum: 400 kg.
  • Bolted dismountable chassis with access ramp.
  • 2 rollers Ø 50mm.
  • 1 roller can be easily adjusted without tools. Allows this roller to handle a wider range of cable drums.
  • No blocking arm for removing cable drum from the roller: given its light weight, the operator can block the roller with his foot.
  • Exterior dimensions: 700 x 790 x 126mm.
  • Weight: 15 kg

OPTIONAL

Locking the incoming roll

  • Anti-return freewheel rolling system.
  • Anti-return freewheel rolling system

Additional Information

Category:

Made in France

Certified compliant machine

Fact sheet

TYPE DAR 1 INDUSTRIAL

CHARACTERISTICS

Designed for unwinding of electrical wires and cables from NF and DIN-standard cable drums:

  • Ø mini : 350 mm.
  • Ø maxi : 1400 mm.
  • Maximum width: 930mm.
  • Total weight: 1500 kg.
  • 1 adjustable roller, to fit different cable drums.
  • 1 locking roller for reel removal.
  • Custom shaped rollers with heavy-duty bearings.
  • Size of apparatus:
    Length: 750mm.
    Width: 1135mm.
    Height: 101mm.
    Total weight: 1500 kg.
  • Weight: 21kg.

TYPE DAR 2 SERIE L

CHARACTERISTICS

For unwinding cable drums

  • Ø mini : 400 / 600 mm.
  • Ø maxi : 900 mm.
  • Maximum weight of cable drum: 250 kg
  • This unwinding roller is composed of 2 parts, to save space when loaded in service vehicles and to economise on weight.

Each part consists of

  • 1 Bolted dismountable chassis with access ramp.
  • 2 rollers Ø 50mm.
  • 1 roller is detachable by bolts. This can reduce the minimum diameter of cable drums handled from 600mm to 400mm.
  • No blocking arm for removing cable drum from DAR: given its light weight, the operator can remove the cable drum from the side.
  • Exterior dimensions: 682 x 690mm.
  • Weight: 4 kg.

DAR 2 INDUSTRIAL

CHARACTERISTICS

Designed for unwinding of electric wires and cables packaged in NF and DIN-standard cable drums

  • Ø mini : 350 mm.
  • Ø maxi : 1650 mm.
  • Total weight: 2500kg

For each piece:

  • 1 adjustable roller, to fit different cable drums.
  • 1 locking roller for reel removal.
  • Custom shaped rollers with heavy-duty bearings.

Encombrement de chaque élément :

  • Length: 711mm.
  • Width: 251mm.
  • Height: 101mm.
  • Weight: 16 kg.
